201 202 stainless steel pipe
Stainless steel is classified into five main families that are primarily differentiated by their crystalline structure:
austenitic
ferritic
martensitic
duplex
precipitation hardening
200 series are chromium-manganese-nickel alloys that maximize the use of manganese and nitrogen to minimize the use of nickel. Due to their nitrogen addition, they possess approximately 50% higher yield strength than 300 series stainless sheets of steel.
Type 201 is hardenable through cold working.
Type 202 is a general-purpose stainless steel. Decreasing nickel content and increasing manganese results in weak corrosion resistance.
Product Details
Stainless steel cannot really be called stainless. It would be more accurate to say that it can stain less than other steels. The reason for this qualification is that stainless steel contains a minimum of 11% Chromium, which allows it to be resistant to rust.
There are various types of stainless steel, each with a set of unique qualities and composition. The chemical composition of the stainless steel determines properties such as strength, hardness, and how magnetic the material is.
You may hear people referring to stainless steel using certain terms and not be exactly clear on their meaning. For more clarification, here are the different categories.
Ferritic – Ferritic stainless steel is magnetic and has a low Carbon count.
Austenitic – this kind of stainless steel is non-magnetic and is a Chromium-Nickel steel like 201, 304, & 316.
Martensitic – this stainless steel is rarely used. It is magnetic and low amounts of Carbon with low levels of Nickel and 12 percent Chromium.
Uses of Stainless Steel 201
Stainless steel grade 201 is a mid-range product typically found in appliances, cookware, sinks, kitchen utensils, and food service equipment. It is also found in automotive parts and clamps as well as railroad cars, and window trim. Its structural integrity and makeup make it ideal for uses in these industries. It tends to not be a good choice, however, for outdoor structural use, because it is susceptible to pitting and crevice corrosion from certain elements like salt water.
Properties of Type 201 Steel (aka T201, type 201 and grade 201)
An austenitic, non-magnetic, stainless steel 201 has the following composition.
It is Chromium (16% – 18%), and Nickel (3.5% – 5.5%). It contains higher amounts of Manganese (5.5%-7.5%) and Nitrogen, and lower amounts of Nickel than type 304 steel.
Increasing costs and the high volatility of Nickel have made Type 201 stainless steel increasingly attractive for certain stainless steel end products. In most applications, there is no loss in resistance to corrosion.
Product Parameters
Chemical Material Composition of SS 201 seamless pipes | ||||||||||
Grade | Mn | C | P | Si | Cr | S | Ni | Mo | N | |
Stainless Steel 201 Seamless Pipe | minimum | 5.5 | – | – | – | 16 | – | 3.5 | – | – |
maximum | 7.5 | 0.15 | 0.06 | 0.75 | 18 | 0.03 | 5.5 | 0.25 |
Mechanical Properties | ||||
Grade | Yield Strength (MPa) | Ultimate Tensile Strength (MPa) | Rockwell Hardness | Elongation at Break (%) |
SUS201 | ≥275 | ≥520 | HRB≤100 | 55-60 |
Product Name | Stainless steel tube / pipe |
Type | Seamless or Welded |
Material (ASTM) | 201 202 304 304L 309s 310s 316 316L 316TI 317L 321 904L S32205/custom |
Material (DIN) | 1.4301 1.4306 1.4541 1.4401 1.4404 1.4571 1.4539 1.44621.4410 1.4833 1.4845 |
Outter Diameter (OD) | 3-1220mm/custom |
Thickness | 0.5-50mm/custom |
Length | 6000mm 5800mm 12000mm or Customized |
Surface Finished | No.1 No.3 No.4 HL 2B BA 4K 8K 1D 2D |
Technique | Cold Drawn or Hot rolled |
Standard | ASTM AISI DIN JIS GB EN |
Application | Construction, Industry, decoration and foodstuff etc. |
Monthly Supply | 5000 Tons |
Delivery Time | 7-10 Working Days after Deposit |
Package | Plywood Case/Pallet or Other Export Package Suitable for Long Distance Shipping |
End/Edge | Plain Mill |
Service | OEM/ODM service |
