A53 carbon steel coil

ss400 s235jr s355jr a53 a36 hot rolled coil MS plate

Structural steel plate:
It is mainly used for the production of steel structures, bridges, ships and vehicles.
Weathering steel plate:
The addition of special elements (P, Cu, C, etc.) has good corrosion resistance and atmospheric corrosion resistance, and is used in the production of containers, special vehicles, and also for building structures.
Hot rolled special steel plate:
Carbon steel, alloy steel and tool steel for general mechanical structure are used in the production of various mechanical parts after heat treatment engineering.
Steel plate for steel tube:
It has good processing performance and compressive strength, and can be used to produce high pressure gas pressure vessels with contents less than 500L filled with LPG, acetylene and various gases.
Application:
Steel plate applies to construction field, ships building industry, petroleum,chemical industries, war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields,etc.

Carbon Steel Pipes and Tubes Specification：

A53 A106 API5L Grade B/C X42 Seamless Pipe
Size Range： 1/8" - 26"
Schedules： 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH
Grades： ASTM A53 Gr B, ASME SA53 Gr B, API-5L Gr B, ASTM A106 Gr B, ASME SA106 Gr B, ASTMA106 GrC, PSL 1 and PSL2
API5L X-42 X-52 X-60 Seamless Pipe
Size Range: 2"- 24"
Schedules: Standard (STD), Extra Heavy (XH), 100, 120, 160, XXH
Grades: PSL1 and PSL2
A333 (Low Temp) Grade 1/6 Carbon Steel Seamless Pipe
Size Range: 1/2" - 24"
Schedules: Standard (STD), Extra Heavy (XH), 100, 120, 160, XXH

Product Parameters

Standard
Grade
Chemical Components (%)
Mechanical Properties
ASTM A53 C Si Mn P S Tensile STrength(Mpa) Yield STrength(Mpa)
A ≤0.25 - ≤0.95 ≤0.05 ≤0.06 ≥330 ≥205
B ≤0.30 - ≤1.2 ≤0.05 ≤0.06 ≥415 ≥240
ASTM A106 A ≤0.30 ≥0.10 0.29-1.06 ≤0.035 ≤0.035 ≥415 ≥240
B ≤0.35 ≥0.10 0.29-1.06 ≤0.035 ≤0.035 ≥485 ≥275
ASTM SA179 A179 0.06-0.18 - 0.27-0.63 ≤0.035 ≤0.035 ≥325 ≥180
ASTM SA192 A192 0.06-0.18 ≤0.25 0.27-0.63 ≤0.035 ≤0.035 ≥325 ≥180
API 5L PSL1 A 0.22 - 0.90 0.030 0.030 ≥331 ≥207
B 0.28 - 1.20 0.030 0.030 ≥414 ≥241
X42 0.28 - 1.30 0.030 0.030 ≥414 ≥290
X46 0.28 - 1.40 0.030 0.030 ≥434 ≥317
X52 0.28 - 1.40 0.030 0.030 ≥455 ≥359
X56 0.28 - 1.40 0.030 0.030 ≥490 ≥386
X60 0.28 - 1.40 0.030 0.030 ≥517 ≥448
X65 0.28 - 1.40 0.030 0.030 ≥531 ≥448
X70 0.28 - 1.40 0.030 0.030 ≥565 ≥483
API 5L PSL2 B 0.24 - 1.20 0.025 0.015 ≥414 ≥241
X42 0.24 - 1.30 0.025 0.015 ≥414 ≥290
X46 0.24 - 1.40 0.025 0.015 ≥434 ≥317
X52 0.24 - 1.40 0.025 0.015 ≥455 ≥359
X56 0.24 - 1.40 0.025 0.015 ≥490 ≥386
X60 0.24 - 1.40 0.025 0.015 ≥517 ≥414
X65 0.24 - 1.40 0.025 0.015 ≥531 ≥448
X70 0.24 - 1.40 0.025 0.015 ≥565 ≥483
X80 0.24 - 1.40 0.025 0.015 ≥621 ≥552
