Advantage

Grade 904L is a non-stabilised low carbon high alloy austenitic stainless steel. The addition of copper to this grade gives it greatly improved resistance to strong reducing acids, particularly sulphuric acid. It is also highly resistant to chloride attack - both pitting / crevice corrosion and stress corrosion cracking.

This grade is non-magnetic in all conditions and has excellent weldability and formability. The austenitic structure also gives this grade excellent toughness, even down to cryogenic temperatures.

904L does have very substantial contents of the high cost ingredients nickel and molybdenum. Many of the applications in which this grade has previously performed well can now be fulfilled at lower cost by duplex stainless steel 2205 (S31803 or S32205), so 904L is used less commonly than in the past.

Product Details

Heat Resistance

Good resistance to oxidation, but like other highly alloyed grades suffers from structural instability (precipitation of brittle phases such as sigma) at elevated temperatures. It should not be used above about 550°C. 904L has design stress values in the ASME Boiler and Pressure Vessel Code to 371°C

Heat Treatment

 Solution Treatment (Annealing)

Heat to 1090-1175°C and cool rapidly. This grade cannot be hardened by thermal treatment

Welding

904L can be successfully welded by all standard methods. Care needs to be taken as this grade solidifies fully austenitic, so is susceptible to hot cracking, particularly in constrained weldments. No pre-heat should be used and in most cases post weld heat treatment is also not required. AS 1554.6 prequalifies Grade 904L rods and electrodes for welding of 904L

Product Parameters
